Description
| Capacity | 1500kg |
| Lift Height | 3300mm |
| Load Centre | 600mm |
| Wheel Base | 1230mm |
| Wheel Type | PU |
| Size of Front Wheel | ￠100mm |
| Size of Drive Wheel | ￠210mm |
| Lowered Height of Fork | 90mm |
| Overall Length | 1705mm |
| Rear Body Width | 820mm |
| Fork Length | 1070mm |
| Outer Width of the Fork | 320mm ~ 685mm |
| Lowered Height of Fork | 85mm |
| Clearance | 30mm |
| Min. Turning Radius | 1425mm |
| Travel Speed | Laden: 4.5km/h | Unladen: 4.7km/h |
| Lift Speed | Laden: 115mm/s | Unladen: 160mm/s |
| Battery | (12V 75Ah) x 2 |
